NB-200D
NB-200D
Product Presentation
Adopt IGBT ＆ advanced PWM inverter technology
High performance 32bit MCU and LCD display
DC MIG,Lift-TIG,MMA function
Are force,hot start can be adjusted in the manual welding
Current dropping and gas aspirated time can be adjusted in the argon arc welding
Selective modules;MEC,VRD,PFC
(Add differernt function module,the parameter and weight will change)
Synergic HOME function automaticaliy manages ideal voltage while only adjusting wire feed speed
Compact,light weight,portable
Compatibal POWER GENERATOR
Intelligent Protection；over-voltage,low-voltage,over-current,over-heat
| NB-200D technical parameters | |||
| MODEL | NB-200D | ||
| MIG | TIG | MMA | |
| Input Voltage(V) | 220/230/240 | ||
| Rated Input Current(A) | 34.8 | 26 | 40.6 |
| Rated Input Power(KW) | 6.1 | 4.6 | 7.2 |
| No Load Voltage(V) | 84 | ||
| Current Range(A) | 5-200 | ||
| Duty Cycle(25℃ 10min) | 200A 40% | 160A 60% | 140A 100% |
| Duty Cycle(40℃ 10min) | 200A 25% | 125A 60% | 100A 100% |
| Protection Class | IP23S | ||
| Insulation Class | F | ||
| Dimensions(mm) | 440×215×405 | ||
| Net Weight(kg) | 14 | ||
